Description
RS485 sensor to integrate with external sensors. Additional Water flow sensor POA.
This sensor is battery powered and connects over LoRaWAN.
X1 Flow Meter (RS485) Sensor
X1 Flow Meter (RS485) Sensor
| Requirements | |
| Connectivity | C-01-18 or C-01-19 or C-07-01 |
| Service | SER-05-01 |
| Support | SupA-05-01 |
| Platform | P-05-01 |
| Reporting | |
| Measuring Period | Every 60 Minutes |
| Data Upload Interval | Minimum of 60 Minutes, but can be customised. |
| Measurements | Support RS485 sensors |
| Physical | |
| Dimensions | (H) 109 mm X (D) 40 mm |
| Temperature Range | Operating Temperature range: • 0 C – 70 C Storage Temperature range: • -40 C – 85 C |
| IP Rating | IP68 |
| Weight | 600 g |
| Connectivity | |
| Connectivity Type | LoRaWAN(AU915 or AS923) |
| Antenna | Built in antenna |
| Transmit Power | Max. 20 dBm |
| Electrical | |
| Power Options | Battery (DC, LiPo, 3.7 V, 3400mAh) |
